SBC-3.5-PX30
Usually ships in 2-4 days
With Rockchip PX30 SoC.
Not available
$15.00
excl. TAX/VAT/SHIPPING
| CPU | Rockchip PX30 processor, 4x Cortex®-A35 cores |
|---|---|
| Graphics | Mali-G31 GPU |
| Connectivity | 1x 10/100 Ethernet port Optional M.2 Socket 1 Key E Slot for WiFi/BT LE external modules Optional miniPCI-e slot (USB interface only) for external modem modules |
| Memory | Soldered-down 2GB DDR3L memory, 32-bit interface. |
SBC-3.5-PX30
| Processor | Rockchip PX30 processor, 4x Cortex®-A35 cores |
|---|---|
| Cores | 4 |
| Memory | Soldered-down 2GB DDR3L memory, 32-bit interface. |
| Graphics | Mali-G31 GPU with High performance dedicated 2D processor OpenGL ES 1.1 / 2.0 / 3.2, Vulkan 1.0, OpenCL 2.0 , DX11 FL9_3 Embedded VPU, able to offer: Multi-format 1080P 60fps video decoders (H.265, H.264,VC-1, MPEG-4, VP8) H.264 1080p@30fps HW encoding Supports 2 independent video outputs |
| Video Interfaces | LVDS Single / Dual Channel interface HDMI® interface HDMI® Up to 1920x1080 LVDS Up to 1280x800 |
| Mass Storage | eMMC 5.1 Drive soldered on-board, up to 64GB Optional microSD Slot |
| Networking | 1x 10/100 Ethernet port Optional M.2 Socket 1 Key E Slot for WiFi/BT LE external modules Optional miniPCI-e slot (USB interface only) for external modem modules |
| Usb | 3x USB 2.0 Host ports on standard Type-A slots USB Recovery internal connector 2x USB 2.0 ports on internal pin headers |
| Audio | PMIC embedded Audio Codec Stereo audio out on internal header TRRS combo jack for Headphone and Mic In Line Out audio jack or I2S Audio Class-D amplifier with stereo out available on internal connector (factory alternatives) Buzzer on-board |
| Serial Ports | 1x TTL or RS-232 port (factory alternative) 1x Debug UART 1x TTL or RS-232 port (factory alternatives to microSD slot) 1x RS-485 port on internal connector 1x CAN port |
| Other Interfaces | miniSIM Slot for optional miniPCI-e modem modules Optional CSI Camera connector Ultra-low Power RTC Trusted Secure Element 4-Channel LED Driver connector Microcontroller Programmable Interfaces: 2x 4-Wire UARTs on internal connector 2x 2-Wire UARTs on internal connector 1x SPI connector 2x I2C on internal connector 8-channel timer connector 16x GPIs @3.3V (5V tolerant) 16x GPOs @3.3V |
| Power Supply | +12VDC ÷ +24 VDC RTC battery |
| Operating System | Linux Yocto Android |
| Dimensions | 146 x 102 mm (3.5form factor) |
| Operating Temperature | 0°C ÷ +60°C (Commercial Temperature range) -20°C÷ +85°C (Extended Temperature range) -* Measured at any point of SECO standard heatspreader for this product, during any and all times (including start-up). Actual temperature w0ill widely depend on application, enclosure and/or environment. Upon customer to consider application-specific cooling solutions for the final system to keep the heatspreader temperature in the range indicated. |
View all specs
View less specs
| Processor | Rockchip PX30 processor, 4x Cortex®-A35 cores |
|---|---|
| Cores | 4 |
| Memory | Soldered-down 2GB DDR3L memory, 32-bit interface. |
| Graphics | Mali-G31 GPU with High performance dedicated 2D processor OpenGL ES 1.1 / 2.0 / 3.2, Vulkan 1.0, OpenCL 2.0 , DX11 FL9_3 Embedded VPU, able to offer: Multi-format 1080P 60fps video decoders (H.265, H.264,VC-1, MPEG-4, VP8) H.264 1080p@30fps HW encoding Supports 2 independent video outputs |
| Video Interfaces | LVDS Single / Dual Channel interface HDMI® interface HDMI® Up to 1920x1080 LVDS Up to 1280x800 |
| Mass Storage | eMMC 5.1 Drive soldered on-board, up to 64GB Optional microSD Slot |
| Networking | 1x 10/100 Ethernet port Optional M.2 Socket 1 Key E Slot for WiFi/BT LE external modules Optional miniPCI-e slot (USB interface only) for external modem modules |
| Usb | 3x USB 2.0 Host ports on standard Type-A slots USB Recovery internal connector 2x USB 2.0 ports on internal pin headers |
| Audio | PMIC embedded Audio Codec Stereo audio out on internal header TRRS combo jack for Headphone and Mic In Line Out audio jack or I2S Audio Class-D amplifier with stereo out available on internal connector (factory alternatives) Buzzer on-board |
| Serial Ports | 1x TTL or RS-232 port (factory alternative) 1x Debug UART 1x TTL or RS-232 port (factory alternatives to microSD slot) 1x RS-485 port on internal connector 1x CAN port |
| Other Interfaces | miniSIM Slot for optional miniPCI-e modem modules Optional CSI Camera connector Ultra-low Power RTC Trusted Secure Element 4-Channel LED Driver connector Microcontroller Programmable Interfaces: 2x 4-Wire UARTs on internal connector 2x 2-Wire UARTs on internal connector 1x SPI connector 2x I2C on internal connector 8-channel timer connector 16x GPIs @3.3V (5V tolerant) 16x GPOs @3.3V |
| Power Supply | +12VDC ÷ +24 VDC RTC battery |
| Operating System | Linux Yocto Android |
| Dimensions | 146 x 102 mm (3.5form factor) |
| Operating Temperature | 0°C ÷ +60°C (Commercial Temperature range) -20°C÷ +85°C (Extended Temperature range) -* Measured at any point of SECO standard heatspreader for this product, during any and all times (including start-up). Actual temperature w0ill widely depend on application, enclosure and/or environment. Upon customer to consider application-specific cooling solutions for the final system to keep the heatspreader temperature in the range indicated. |
View all specs
View less specs
3.5” SBC with Rockchip PX30 SoC, 2GB DDR3L, 16GB eMMC.
