SOM-COMe-CT6-V2748
623,25 €
SOM-COMe-CT6-V2748
Solitamente spedito in 2-4 giorni
Con AMD V2748 (8C/16T @2.9GHz, Boost up to 4.15 GHz, Radeon Graphics w/ 7 CU, TDP 35-54W).
Disponibile
623,25 €
escl. IVA/SPEDIZIONE
| CPU | AMD Ryzen™ Embedded V2748 with AMD Radeon™ Graphics with 7CU, Eight Core Dual Thread @ 2.9GHz (4.15 Boost), TDP 35-54W |
|---|---|
| Graphics | Integrated AMD Radeon™ GPU with 7 Compute Units |
| Connectivity | Gigabit Ethernet interface with Intel® I21x GbE Controller Optional M.2 1216 WiFi 802.11ac and BTLE 5.0 on-board |
| Memory | Two DDR4 SO-DIMM Slots supporting DDR4-3200, ECC and non- ECC modules. Memory, up to 64GB |
SOM-COMe-CT6-V2748
| Processore | AMD Ryzen™ Embedded V2748 with AMD Radeon™ Graphics with 7CU, Eight Core Dual Thread @ 2.9GHz (4.15 Boost), TDP 35-54W |
|---|---|
| Core | 8 |
| Memoria | Two DDR4 SO-DIMM Slots supporting DDR4-3200, ECC and non- ECC modules. Memory, up to 64GB |
| Scheda Grafica | Integrated AMD Radeon™ GPU with 7 Compute Units |
| Interfacce Video | Up to 3 x Digital Display Interfaces (DDIs), supporting DVI, DP 1.4, HDMI 2.1 1 x eDP 1.3 or Single/Dual-Channel 18-/24-bit LVDS interface eDP, DP up to 4096x2160 @60Hz 10b with DSC 1.2 (HBR3) HDMI up to 4096x2160 @ 60Hz LVDS up to 1920x1200 @ 60Hz |
| Memoria Di Massa | 2 x S-ATA Gen3 Channels |
| Rete | Gigabit Ethernet interface with Intel® I21x GbE Controller Optional M.2 1216 WiFi 802.11ac and BTLE 5.0 on-board |
| Usb | 1 x SuperSpeed USB 10Gbps Host ports 3 x SuperSpeed USB 5Gbps Host ports 8 x 2.0 Host ports |
| Audio | HD Audio interface |
| Porte Seriali | 2 x UARTs |
| Altre Interfacce | 8 x PCI-e x1 Gen3 lanes PCI-express Graphics (PEG) x8 Gen3 SPI, I2C, SM Bus, Thermal Management, FAN management LPC bus Optional TPM 2.0 on-board LID#/SLEEP#/PWRBTN#, Watchdog 4 x GPI, 4 x GPO |
| Alimentazione | 8VDC..20VDC, +5VSB (optional), +3VRTC (optional) |
| Sistema Operativo | Microsoft® Windows 10 Linux |
| Dimensioni | 95 x 95 mm (COM Express® Compact Form factor, Type 6 pinout) |
| Operating Temperature | 0°C ÷ +60°C (Commercial version)* * Measured at any point of SECO standard heatspreader for this product, during any and all times (including start-up). Actual temperature will depend on the application, enclosure, and/or environment. Each customer must consider application-specific cooling solutions for the final system to keep the heatspreader temperature in the range indicated. |
Visualizza tutte le specifiche
Visualizza meno specifiche
| Processore | AMD Ryzen™ Embedded V2748 with AMD Radeon™ Graphics with 7CU, Eight Core Dual Thread @ 2.9GHz (4.15 Boost), TDP 35-54W |
|---|---|
| Core | 8 |
| Memoria | Two DDR4 SO-DIMM Slots supporting DDR4-3200, ECC and non- ECC modules. Memory, up to 64GB |
| Scheda Grafica | Integrated AMD Radeon™ GPU with 7 Compute Units |
| Interfacce Video | Up to 3 x Digital Display Interfaces (DDIs), supporting DVI, DP 1.4, HDMI 2.1 1 x eDP 1.3 or Single/Dual-Channel 18-/24-bit LVDS interface eDP, DP up to 4096x2160 @60Hz 10b with DSC 1.2 (HBR3) HDMI up to 4096x2160 @ 60Hz LVDS up to 1920x1200 @ 60Hz |
| Memoria Di Massa | 2 x S-ATA Gen3 Channels |
| Rete | Gigabit Ethernet interface with Intel® I21x GbE Controller Optional M.2 1216 WiFi 802.11ac and BTLE 5.0 on-board |
| Usb | 1 x SuperSpeed USB 10Gbps Host ports 3 x SuperSpeed USB 5Gbps Host ports 8 x 2.0 Host ports |
| Audio | HD Audio interface |
| Porte Seriali | 2 x UARTs |
| Altre Interfacce | 8 x PCI-e x1 Gen3 lanes PCI-express Graphics (PEG) x8 Gen3 SPI, I2C, SM Bus, Thermal Management, FAN management LPC bus Optional TPM 2.0 on-board LID#/SLEEP#/PWRBTN#, Watchdog 4 x GPI, 4 x GPO |
| Alimentazione | 8VDC..20VDC, +5VSB (optional), +3VRTC (optional) |
| Sistema Operativo | Microsoft® Windows 10 Linux |
| Dimensioni | 95 x 95 mm (COM Express® Compact Form factor, Type 6 pinout) |
| Operating Temperature | 0°C ÷ +60°C (Commercial version)* * Measured at any point of SECO standard heatspreader for this product, during any and all times (including start-up). Actual temperature will depend on the application, enclosure, and/or environment. Each customer must consider application-specific cooling solutions for the final system to keep the heatspreader temperature in the range indicated. |
